Field-ready SRP VSD panel built on the IQLogic™ intelligent control platform, integrating motor control, protection systems, HMI visibility, and industrial communications for reliable rod-lift operation and remote monitoring.
IQLogic is a field-ready SRP VSD control panel engineered for stable motor speed control, protection, and clear operator visibility. It combines VSD control, protection relays, power-quality components, and an HMI touchscreen in a single enclosure with Modbus RTU/TCP connectivity. Designed for harsh sites, it supports remote monitoring and integration with SCADA and PLC systems.
| Parameter | Specification |
|---|---|
| Power Rating | 30–150 HP (configurable) |
| Input Voltage | 380–480 VAC, 3-phase (±10%) |
| Input Frequency | 50/60 Hz (±5%) |
| Output Frequency | 0.01–500 Hz |
| Efficiency | ≥98% |
| Overload Capacity | 150% for 1 min; 180% for 2 sec |
| Motor Control | SVC (sensorless vector) or V/Hz |
| Protection Relays | Surge, overvoltage, overcurrent, short circuit, earth fault, E-stop, and auto-restart (configurable). |
| Harmonics | Passive harmonic filter option; AFE option to meet IEEE-519 targets (<5% THD). |
| Enclosure | IP55 (minimum) cabinet with forced-air cooling |
Get a quote for your IQLogic SRP VSD panel or speak directly with the engineering team.
